TSC DA320 Desktop Barcode Printer in Sikkim
TSC DA320 Desktop Barcode Printer TSC DA320 Desktop Barcode Printer

Because it prints direct thermal only, the DA320 needs no ribbon, which keeps running costs and operator training to a minimum. Its double-walled clamshell opens wide for drop-in loading of rolls up to 5 inches in diameter, and a spring-loaded, centre-biased holder keeps both narrow and wide media aligned.

The 300 dpi printhead makes the DA320 a good fit for Indian pharmacies, hospital sample-collection desks, e-commerce sellers printing courier labels and retailers who need small barcodes on price stickers. Wi-Fi and Bluetooth factory options plus cutter, peeler and linerless kits let the same printer grow with the job.

Barcode Vault is a sales and service provider for TSC barcode printers and printheads across India. For the best price call 8527522688 or mail us at gm@indianbarcode.com.

  • Key Features

    • Print resolution: 12 dots/mm (300 dpi)
    • Max. print speed: 102mm (4")/second
    • Max. print width: 105.7mm (4.16")
    • Wired connectivity: Ethernet; Serial RS-232; USB; USB Host
    • Direct thermal printing, no ribbon needed
    • Gap, black mark and head-open sensing
    • Compact double-walled clamshell body weighing about 1.5 kg
    • Factory options for 802.11 a/b/g/n Wi-Fi and Bluetooth
    • TSPL-EZD firmware compatible with EPL, ZPL, ZPL II and DPL

    Applications

    • Courier and e-commerce shipping labels
    • Pharmacy and specimen labels
    • Retail price stickers
    • Mail-room address and routing labels
    • Patient tracking
    • Event and transport ticketing
  • Printing
    Resolution12 dots/mm (300 dpi)
    Printing MethodDirect Thermal
    Max. Print Speed102mm (4")/second
    Max. Print Width105.7mm (4.16")
    Max. Print Length11,430mm (450")
    Physical
    EnclosureDouble-walled plastic
    Physical Dimension172mm (W) x 165mm (H) x 195mm (D) / 6.77" (W) x 6.50" (H) x 7.68" (D)
    Weight1.5kg (3.31lbs)
    Hardware
    Processor32-bit RISC CPU
    Memory128 MB Flash memory; 64 MB DRAM
    Operation Switch, Button, LED1 power switch, 1 feed button, 1 LED (3 colors: green, amber & red)
    SensorsTransmissive gap sensor; Black mark reflective sensor; Head open sensor
    Connectivity
    InterfacePCBA1: USB 2.0 high speed mode, USB Host, RS-232 and Ethernet (standard); PCBA2: USB 2.0 and Ethernet (factory option); Internal 802.11 a/b/g/n wireless (factory option); Internal Bluetooth (factory option)
    Hardwire ConnectivityEthernet; Serial RS-232; USB; USB Host
    Wireless ConnectivityBluetooth; Bluetooth MFi; Wi-Fi
    Enterprise Printer ManagementTSC Console
    Media & Ribbon
    Label Roll Capacity127mm (5") O.D.
    Media TypeContinuous, black mark, fan-fold, notched (outside wound)
    Media Width19mm - 114mm (0.7" - 4.5")
    Media Thickness0.055mm - 0.19mm (2.16mil - 7.48mil)
    Media Core Diameter25.4mm - 38mm (1" - 1.5")
    Label Length10mm - 11,430mm (0.39" - 450")
    Fonts, Barcodes & Language
    Internal Fonts8 alpha-numeric bitmap fonts; Monotype Image® true type font engine with one CG Triumvirate Bold Condensed scalable font
    Barcode1D barcode Code 39, Code 93, Code128UCC, Code128 subsets A.B.C, Codabar, Interleaved 2 of 5, EAN 8, EAN 13, EAN 128, UPC-A, UPC-E, EAN and UPC 2(5) digits add-on, MSI, PLESSEY, POSTNET, China post, ITF14, EAN14, Code 11, TELEPEN, TELEPENN, PLANET, Code 49, Deutsche Post Identcode, Deutsche Post Leitcode, LOGMARS; 2D barcode TLC39, CODABLOCK F mode, PDF-417, Maxicode, DataMatrix, QR code, Aztec, Micro PDF 417, GS1 DataBar (RSS barcode)
    Font and Barcode Rotation0, 90, 180, 270 degree
    Printer LanguageTSPL-EZD (Compatible with EPL, ZPL, ZPL II, DPL)
    Power
    PowerExternal universal switching power supply; Input: AC 100-240V, 2.0A, 50-60Hz; Output: DC 24V, 2.5A, 60W
    Environment & Compliance
    Environment ConditionOperation: 5°C to 40°C (41°F to 104°F), 25% - 85% non-condensing; Storage: -40°C to 60°C (-40°F to 140°F), 10% - 90% non-condensing
    Safety RegulationCB, FCC Class A, IC , CE Class A, UKCA, EAC, CCC, BIS, RCM, BSMI, KC, Energy Star 3.2
    Environment ConernComply with RoHS, REACH, WEEE, China RoHS
    Warranty & Options
    AccessoriesQuick start guide; USB cable; Power cord; External universal switching power supply
    Limited WarrantyPrinter: 2 years; Printhead: 25km (1 million inches) or 12 months which comes first; Platen: 50km (2 million inches) or 12 months which comes first
    Factory OptionsReal Time Clock; Internal 802.11 a/b/g/n wireless; Internal Bluetooth; Internal MFi Bluetooth; PCBA2: USB2.0 and Ethernet
    Dealer OptionsPeel-off module; Guillotine cutter (full cut or partial cut); Linerless with cutter; Linerless with cutter (enhanced); Linerless with tear
    User Options1.5" adaptor for 1.5" paper core; External roll mount, media O.D. 214mm (8.4") with 76.2mm (3") core; KP-200 Plus keyboard display unit (serial interface)
    General
    TypeDesktop
    • Health careTSC DA320 Desktop Barcode Printer can be used in Health care Industry
    • RetailsTSC DA320 Desktop Barcode Printer can be used on Retail Stores
    • LogisticsTSC DA320 Desktop Barcode Printer Mostly used in Logistics Industry for Asset Management and Tracking
    • ManufacturingManufacturing Industry uses TSC DA320 Desktop Barcode Printer
    • GovernmentTSC DA320 Desktop Barcode Printer used in various Government Sectors
    • Travel & LeisureTSC DA320 Desktop Barcode Printer for Travel & Leisure
    • Special MaterialsTSC DA320 Desktop Barcode Printer for Special Materials
