Dimensions: The machine measures 3.7 inches in height, 11.61 inches in width, and 11.54 inches in length, making it compact and easy to carry.

Weight: The unit weighs 5.3 lbs, ensuring portability for field and workshop use.

Printing Method: Uses a Thermal Transfer printing method with a high-resolution 300 dpi output for clear and durable marking.

Display: Equipped with a backlit LCD dot-matrix display (64 × 160 pixels) for easy navigation and visibility in all lighting conditions.

Printing Speed: Offers standard printing at 40 mm/s and 20 mm/s in low-temperature mode.

Maximum Printing Length: Supports up to 100 meters for tube printing and 5 meters for tape printing. With multiple-copy printing (up to 30 copies), the tape length extends up to 7 meters.

Maximum Characters Input: Allows up to 5,000 characters per file, enabling long and detailed labeling tasks.

Character Sizes: Supports character heights of 1.3 mm, 2 mm, 3 mm, 4 mm, and 6 mm.

Usable Tube Range: Compatible with PVC tubes of 1.5 mm to 8.0 mm diameter, and heat-shrink tubes from 2.0 mm to 6.5 mm. (Grip tube 1.5–2.0 mm requires a dedicated attachment.)

Usable Tape: Accepts genuine tape widths of 5 mm, 9 mm, and 12 mm.

Tube Cutting Method: Features auto half-cut for rapid production and manual full-cut for complete tube separation.

Internal Memory: Stores up to 250,000 characters, with a maximum capacity of 50 files.

External Memory: Supports USB memory storage for easy data transfer.

Interface: Equipped with USB 2.0 full-speed connectivity for efficient data communication.

Power Supply: Operates on DC 12V, 4.2A using the specified AC adapter (100V–240V). It also supports operation with 4 AA batteries for portable use.

Power Consumption: Maximum power usage is 40W.

Operating Environment: Designed to operate reliably within a temperature range of 10°C to 35°C.
