HPRT TP809 Label Printer

4" Thermal Transfer Label Printer

•  Integrated Mechanism Design
•  Extra Large Paper Roll Windows
•  Auto Label Type Detection
•  Software Kit and Optional Accessory


  • •  Fashionable Design
    •  2” and 3” paper width available
    •  Cutter jam auto-elimination
    •  Support black mark detection



  • PrintingPrint MethodDirect Thermal
    Resolution203 dpi (8 dots/mm)
    Print SpeedMax. 260 mm/s
    Printing WidthMax. 80 mm
    InterfaceStandardUSB Type B, Serial Port, Ethernet
    OptionalBluetooth, Wi-Fi
    Page ModeSupport
    MemoryRAM16 MB
    Flash16 MB
    Programming LanguageESC/POS
    FontsAlphanumeric; Simplified Chinese, Traditional Chinese; 46 International Character Sets
    BarcodeLinear BarcodesUPC-A, UPC-E, EAN-8, EAN-13, CODE 39, ITF, CODEBAR, CODE 128, CODE 93
    2D BarcodesPDF417, QR code
    GraphicsSupport bitmap printing with different density and user defined bitmap printing. (Max size of each bitmap is 64 KB, the total size of bitmap is 256 KB)
    SensorsStandardPaper out Detector, Head up Detector, Black mark Detector
    OptionPaper near end sensors
    LED IndicatorPowerGreen
    BusyBlue
    Paper Near EndPink
    ErrorRed
    Power SupplyInputAC 100V ~ 240V, 50/60Hz
    OutputDC 24V, 2A
    PaperPaper TypeThermal Receipt Paper
    Paper WidthMax. 80mm
    Paper Thickness0.056 ~ 0.13mm
    Roll Paper DiameterMax. Φ83 mm (O.D)
    Paper LoadTop paper loading
    Paper CutPartial cut or Full cut
    EnvironmentOperating0°C ~ 45°C, 20% ~ 85% R.H, no-condensation
    Storage-20°C ~ 70°C, 5% ~ 95% R.H, no-condensation
    Physical CharacteristicsDimensions165(L)×130(W)×119(H) mm
    Weight1.35 kg
    Options and AccessoriesUSB/Serial Cable, Paper roll, Power Adapter, Power Cord, CD, Quick Start Guide
    ReliabilityTPH life150 km
    Cutter2 million cuts
    SoftwareDriverWindows XP/ 7/ 8/ 10; POS Ready; Linux; OPOS
    SDKWinCE, Windows Mobile, Android

  • Healthcare icon HPRT TP809 Label Printer can be used in Health care Industry
    Retails icon HPRT TP809 Label Printer can be used on Retail Stores
    Logistics icon HPRT TP809 Label Printer Mostly used in Logistics Industry for Asset Managemnet and Tracking
    Manufacturing icon Manufacturing Industry uses HPRT TP809 Label Printer
    Government icon HPRT TP809 Label Printer used in various Government Sectors
    Travel & Leisure icon HPRT TP809 Label Printer for Travel & Leisure
    Special Materials icon HPRT TP809 Label Printer for Special Materials
